New Member

Question

Timeout while connecting

Hello ,

The vpn was working fine for 1 week, then i received this error, and i cannot connect again

i tried to connect with a different 4 ISP but same problem

so what i suppose to do

thank you
new .png

Staff

Hi,

Are you using ssl vpn or the ipsec dial up?

What is FGT and FCT version?

What are you observing in the VPN event logs

Thanks, Salon

New Member

Hello @sjoshi ,

Thank you for your reply , i am not technical but here you are a screenshot with the settings

Screenshot 2025-09-22 203714.png

New Member

@sjoshi if you need more info tell me please

Staff

this issue usually occur when the connectivity is broken.

further can you try collect sniffer on the FGT.

Open FGT CLI console

diag sniff packet any 'host x.x.x.x and (port 500 or port 4500)' 4 0 l >> where x.x.x.x is the PC public IP

Thanks, Salon

Staff

Hello @shalaby120

It appears that the FortiClient and FortiGate's Phase 1 and Phase 2 DH group settings are not matching.

Please also check the authentication settings in the IKE proposals in both phases.

regards,

Sheikh

If you have found a solution, please like and mark it as solved to make it easily accessible for everyone.
