delete vlan

Hi @bsgroup - Try removing the logical interface using the CLI. First, use the command show | grep -if "vlan macchine" to identify all references to the VLAN interface, and then start removing them before deleting the VLAN interface altogether.

Here's an example of how to do it:

Saga-kvm04 # show | grep -if "vlan macchine"
config system interface
edit "vlan macchine" <---
set vdom "root"
set ip 192.168.1.1 255.255.255.0
set device-identification enable
set role lan
set snmp-index 16
set interface "port4"
set vlanid 10
next
end
config system dhcp server
edit 2
set dns-service default
set default-gateway 192.168.1.1
set netmask 255.255.255.0
set interface "vlan macchine" <---
next
end
config firewall address
edit "vlan macchine address" <---
set uuid 17672e78-c98a-51ee-674e-089f261443b2
set type interface-subnet
set subnet 192.168.1.1 255.255.255.0
set interface "vlan macchine" <---
next
end

Saga-kvm04 # config firewall address

Saga-kvm04 (address) # del "vlan macchine address"

Saga-kvm04 (address) # end

Saga-kvm04 # config system dhcp server

Saga-kvm04 (server) # del 2

Saga-kvm04 (server) # end

Saga-kvm04 # config system interface

Saga-kvm04 (interface) # del "vlan macchine"

Saga-kvm04 (interface) # end

Saga-kvm04 #
