Continuous CLI Command Configuration

  • December 14, 2023
  • 1 reply
  • 3053 views

hi,

is it possible to configure continously using CLI instead of type 'end' in each configuration section.

for example, after i've configured mgmt ip i can go straight to 'config router static' and type 'end' after the mgmt and static default route are configured? or will the system reject it?



edit - i just tried and indeed rejected the command when i go straight to 'config router static'

is there a way to type commands continuously or is it required typing 'end' each config section?



FG# config system interface

FG(interface) # edit mgmt

FG(mgmt) # set ip 192.168.200.202/24

FG(mgmt) # set allowaccess ping ssh https

FG(mgmt) # end   <<< CAN I SKIP THIS?


FG # config router static

FG(static) # edit 99
new entry '99' added

FG(99) # set dst 0.0.0.0/0

FG(99) # set gateway 192.168.200.1

FG(99) # set device mgmt

FG(99) # end



-----



FG(mgmt) # set allowaccess ping ssh https

FG(mgmt) # config router static

command parse error before 'router'
Command fail. Return code 1

Best answer by AntonyChen

I think no, "end" tag tell the system to finish your configuration for that section, unless you want to continue to config other same level object you can use "next" to continue, otherwise end tag must be used.

in your case you typed FG(mgmt) # config router static  , this is in  "mgmt " and this cli is invalid since it does not exist there.

1 reply

AntonyChen
AntonyChenAnswer
Explorer II
December 14, 2023

I think no, "end" tag tell the system to finish your configuration for that section, unless you want to continue to config other same level object you can use "next" to continue, otherwise end tag must be used.

in your case you typed FG(mgmt) # config router static  , this is in  "mgmt " and this cli is invalid since it does not exist there.
