Technical Tip: How to reset a FortiGate with the default factory settings/without losing management access

[dbabic]

Description

This article describes how to reset a FortiGate to factory defaults.

Scope

This command works on FortiGates and FortiProxys.

Solution

This procedure clears all changes made to the FortiGate configuration and resets the system to its original configuration with the default factory settings.

It does not change the firmware version or the antivirus or IPS  attack definitions.

There is also an option to reset FortiGate to factory settings without losing management access.

A FortiGate Device can be reset to Factory defaults by using the CLI interface. This reset will remove all configurations. It will be out of the box condition. Direct access to FortiGate will be needed to access it.

1. Open an SSH to the system and execute the following command:

execute factoryreset

2. A warning will appear.

This operation will reset the system to factory default!
Do you want to continue? (y/n)

3. The system will reboot and will load a basic configuration.

Note:

This option will require username and password. In case of a lost admin password, a console cable is required to enter the boot menu during the boot-up process. To access the boot menu, press any key when the message 'Press any key to display configuration menu...' appears. After that, choose option I to enter 'System configuration and information' and option E to reset the system configuration:

Factory reset without losing management access.

This option will reset the device to factory settings except for VDOM, interface, and static route settings. This means that after resetting, FortiGate will not have any firewall policies or IPsec settings, but it will be possible to access the FortiGate remotely on its IP address.

This option is available only in CLI:

Open an SSH to the system and execute the following command:

execute factoryreset2

This operation will reset the device to factory settings except for a few specific sections related to VDOMs, interfaces, and static route settings. The following is a list of configuration sections that remain unchanged after using the factoryreset2 command:

• system.global.vdom-mode
• system.global.long-vdom-name
• system.virtual-switch
• system.interface
• system.settings
• router.static
• router.static6

    Do you want to continue? (y/n) --> This warning will appear after running the command.

Since FortiOS v7.0, it is also now a possible option to keep central management configurations after factory-reset. The command below resets the FortiGate to the factory default, except system.central-management.serial-number/system.central-management.fmg.

execute factoryreset-for-central-management

The option below in all versions:

factoryreset-shutdown <- Reset to factory default and shutdown.

Note:

After a reboot, FortiGate will have its factory default settings but still have management access available. The default management IP is 192.168.1.99.

All administrators will be removed and FortiGate can be accessed with the default credentials (admin/{no password}).

After a factory reset, all existing logs stored in memory/disk will be erased. Only new logs generated from the FortiGate's restart will be available.

If the user cannot perform the above-mentioned steps and wants to factory format the unit using an external button, follow the instructions on this KB article: How To Reset To Factory Default Configuration using an external button
