Technical Tip: Pending mode status shows when enabling single sign-on as an auto mode in security fabric on downstream devices

[tpatel]

Description	This article describes how to resolve pending mode status alerts when single sign-on is set to auto on downstream FortiGate.
Scope	FortiGate.
Solution	In the example above, FortiGate A is the root of the security fabric, and FortiGate B is one of the members joining the Security Fabric as a downstream device. Navigate to System-> Fabric Connectors-> Security Fabric Setup. Enable Security Fabric on FortiGate B and authorize FortiGate B on FortiGate A in root fabric. On FortiGate B when SAML single sign-on is set as auto mode, the mode shows 'Pending' status and gives the following error: 'Waiting for the root FortiGate in the Security Fabric to automatically set this device to be in Service Provider mode. The root FortiGate must be configured as Single Sign-On Identity Provider'. While the above error shows up on FortiGate B, it is caused by following the SAML SSO settings on FortiGate A. Navigate to System -> Fabric Connectors -> Security Fabric Setup-> SAML Single Sign-On Advanced Option. To resolve this configure FortiGate A as an IDP for SAML SSO. If a downstream FortiGate needs to be configured through root FortiGate for single sign-on using Security Fabric, the root FortiGate (FortiGate A) must be set to be the identity provider(IDP) and not configured as a service provider(SP). Navigate to System -> Fabric Connectors -> Security Fabric Setup -> SAML Single Sign-On Advanced Option. Once the root FortiGate is set as the identity provider, the downstream FortiGate (FortiGate B) is automatically set to be a SAML service provider and redirects login to the IDP when doing an HTTPS administrative login. It will no longer show a pending status error. Related document:  Configuring single-sign-on in the Security Fabric
