Technical Tip: Devices are unable to get an IP address from DHCP server

[kaurs]

Description	This article describes the vci-match enable/disable option.
Scope	FortiGate.
Solution	Connected devices are not able to get an IP address from the DHCP server configured on FortiGate's interface and get the following error using the DHCP debug command. diagnose debug reset diagnose debug application dhcps -1 diagnose debug enable SC-FG100F # [debug]locate_network prhtype(1) pihtype(1) [warn]Can't locate subnet in shared network of packet and packet is not a DHCPREQUEST and htype(1) != intf htype(1)..dropping [debug]locate_network prhtype(1) pihtype(1) This could be because vci-match is enabled and vci-string is configured on that interface’s DHCP server. For example: config system dhcp server     edit 1         set dns-service default         set default-gateway 10.2.2.131         set netmask 255.255.255.0         set interface "port3"             config ip-range                 edit 1                     set start-ip 10.2.2.133                     set end-ip 10.2.2.133                     set vci-match enable                     set vci-string "FortiSwitch"                 next In this example, devices that match vci-string 'FortiSwitch' only would be able to connect otherwise will not get an IP. The solution would be to either disable the vci-match or configure an appropriate vci-string. config system dhcp server     edit 1         config ip-range             edit 1                 set vci-match disable         end end Or: config system dhcp server     edit 1         set vci-match disable     next end Note: After disabling vci-match the end system runs the below commands and clears the DHCP process, post that the end system got DHCP IP from the DHCP pool. Type 'ipconfig /release' (no quotes) and press 'Enter'. Once the prompt returns, type 'ipconfig /renew' (no quotes), then hit 'Enter'. Related document: VCI pattern matching for DHCP assignment
