Description This article describes how to connect to the FortiGate management IP using SSH.
Scope

FortiGate.

Solution

Prerequisites:

  • Terminal Software like Putty.



  1. Ensure that SSH access is enabled on the interface for the SSH connection. For example, in the scenario, a connection will be attempted via SSH using the 'internal' interface when only HTTPS is enabled. (This configuration can be applied to any interface on the FortiGate):





  1. Edit the Interface and enable SSH:


Select 'OK and confirm the changes.  Now the interface should look like this:




  1. Run the preferred terminal software and configure the connections as follows:
  • Host Name (or IP address): The FortiGate´s Interface IP, in this example 192.168.10.1.
  • Port: 22 (default TCP SSH Port)




  1. Select 'Open' to launch a CLI window. Enter the Administrator Credentials as requested (the same ones used for HTTPS access to the FortiGate). Press 'Enter, input the password, and press 'Enter' again.


The CLI access to the FortiGate through SSH is now available.



Related article:

Troubleshooting Tip: FortiGate HTTPS,SSH access
