Troubleshooting Tip: Application is missing in the Communication Control

[Ahmed_Mohamed]

Description	This article describes how to troubleshoot when a communicating application is missing from the Communication Control tab.
Scope	FortiEDR.
Solution	FortiEDR Applications Communication Control feature maps all applications in the FortiEDR protected devices that communicate externally. After that, decide which of these applications to allow or deny. For further information about the Communication Control feature, refer to the Admin Guide The APPLICATIONS page lists all communicating applications detected in the organization that have ever attempted to communicate. In case specific application(s) is not present, perform the following troubleshooting steps:      1. Make sure to search for the application in the list filtered by All. Verify Collector is running by: The collector is Running in the FortiEDR console INVENTORY -> Collectors and run the command to check the status: Windows: C:\Program Files\Fortinet\FortiEDR\FortiEDRCollectorServices.exe --status Linux: sudo /opt/FortiEDRCollector/control.sh --status macOS: sudo /Applications/FortiEDR.app/fortiedr_collector.sh status Verify Collector has established TCP connection to the Aggregator IP on port 8081 with the command: Windows: netstat -an | findstr 8081 Linux/macOS: netstat -an | grep 8081 Confirm Collector has stable connectivity to the Core, by: Check if Collector flips from degraded due to Core connectivity issues and running states searching with Device Name in Administration -> System Events. Verify Collector has established connectivity to the Core IP on TCP port 555, running the command: Windows: netstat -an | findstr 555 Linux/macOS: netstat -an | grep 555 If the issue persists, raise a TAC ticket providing following information: Collector logs as described in the Technical Tip: How to collect FortiEDR Collector log Commands output: Windows: netstat -an | findstr 8081 netstat -an | findstr 555 Linux/macOS: netstat -an | grep 8081 netstat -an | grep 555 In the case of An on-premise environment, obtain both System logs and Core logs How To Export System logs
