Technical Tip: Collect key information to collect and analyze a crash event

[JordAnge]

Description	This article describes which information should be collected and shared with the TAC-Support to analyze the root cause of a crash event.
Scope	FortiADC.
Solution	From CLI, collect the output of the commands below, the latest ones are related to the crash event that was recorded in FortiADC: exe date get sys status get sys performance diagnose hardware get sysinfo cpu diagnose hardware get sysinfo interrupts diagnose hardware get sysinfo partition diagnose hardware get sysinfo df diagnose hardware get sysinfo memory get sys ha-status get sys vdom-status diagnose system top    <----- Press 'Shift + P' 5 times. (sort by CPU usage). diagnose system top    <----- Press 'Shift + M' 5 times. (sort by MEM usage). diagnose tech-report fnsysctl ls var/log --------------------------------- diagnose crash list diagnose crashlog upload <ftp | tftp> <file_name | all> <TFTP-Server> Example: (P) FortiADC-10 (root) # diagnose crash list 6.6M Oct 5 16:32 named-4032-1665005553.gz 6.5M Oct 5 16:17 named-4861-1665004653.gz 6.6M Oct 5 15:58 named-4674-1665003523.gz 6.5M Oct 5 15:47 named-4791-1665002833.gz 6.5M Oct 5 11:30 named-4486-1664987401.gz (P) FortiADC-10 (root) # diagnose crashlog upload tftp <file_name>    file name all    all log file (P) FortiADC-10 (root) # diagnose crashlog upload tftp all 1.0.16.2 crash.tar            100% |****************************************************************************************************************************************************************************************| 33529k  0:00:00 ETA From GUI, navigate to System -> Debug and Save Debug File. Wait until the status changes to Ready before downloading. Share this information collected and a backup-configuration with the TAC-Support.
