Troubleshooting Tip: fcnacd error: 'Certificate user does not have access to global.'

[acevik]

Description	This article describes how to troubleshoot the fcnacd error: 'Certificate user does not have access to global.'.
Scope	FortiGate.
Solution	Debugging fcnacd: diagnose debug reset diagnose debug application fcnacd -1 diagnose debug console timestamp enable diagnose debug enable Sample error message in debug: [ec_ez_worker_base_prep_resolver:374] Outgoing interface index 0 for 1 (ems.fortinet.com). [ec_ez_worker_prep_data_url:184] Full URL: https://ems.mfs.eos-ts.com/api/v1/system/serial_number [ec_ez_worker_base_prep_ssl:423] verify peer method: 4, current ssl_cb: (nil), new ssl_cb: 0xa13b60 [ec_ems_context_submit_work:519] Call submitted successfully. obj-id: 0, desc: REST API to get EMS Serial Number., entry: api/v1/system/serial_number. [__get_ec_fctems_certificate_info:431] ems cert ca_cn: C = DE, ST = Hamburg, L = Hamburg, O = Fortinet, CN = EOS IT Services Internal Server Issuing CAxaaspfems01.eos.lcl [__get_ec_fctems_certificate_info:432] ems cert fingerprint: XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX [__match_server_cert_key:487] verify_peer_method: 4 [__match_server_cert_key:505] ret=1 [ec_ez_worker_process:368] Processing call for obj-id: 0, entry: "api/v1/system/serial_number" [ec_ez_worker_process:387] reply: """ {"result": {"retval": -5, "message": "Certificate user does not have access to global."}} The above error is prompted when EMS is configured in multi-tenant mode and FortiGate is not configured with the correct domain name which is the requirement of EMS in multi-tenant mode. The most common reason for this error is providing only the global domain name in EMS connector settings such as in the above example: global FQDN is 'ems.fortinet.com'. The domain name should have been provided as follows: <tenant-name>.<global-fqdn> Important Note: FortiGate should be able to resolve the subdomain. In the following example, the EMS server is configured in multi-tenant mode. When multitenancy is enabled initially there are two sites: global, where global settings can be set and viewed, and default. The following example has configured site 'office'. To create a fabric connector with the 'office' tenant, the correct domain name should be 'office.ems.fortinet.com'
