Troubleshooting Tip: High CPU Usage Caused by sslvpnd Due to Missing Key File

[wmichael]

Description	This article describes an issue where the sslvpnd process can cause high CPU usage due to a missing .key file while trying to open the configured certificate.
Scope	FortiGate.
Solution	Analyzing high CPU usage see: Technical Tip: Debugs for troubleshooting high CPU Issues If it has been determined that the high CPU usage is being caused by the sslvpnd process, run the SSL VPN debug to help determine what the process is doing. diagnose debug application sslvpn -1 diagnose debug enable If the following logs are seen, they indicate that the process cannot open the .key file used for the configured certificate in SSL VPN settings. [23502:root:0]set cert: root_certificate.cer key: root_certificate.key [23502:root:0]common_create_ssl_srv_ctx:1710 cipher list: HIGH:!RC4:!MD5:!aNULL:!eNULL:@STRENGTH:!SHA1:!SHA256:!SHA384 [23502:root:0]common_create_ssl_srv_ctx:1734 ciphersuite list: TLS_AES_256_GCM_SHA384:TLS_CHACHA20_POLY1305_SHA256:TLS_AES_128_GCM_SHA256 [23497:root:0]Reading root_certificate.key for server [0]:4443 [23497:root:0]Can't open key file /etc/cert/local/ root_certificate.key [7732:root:0]sslvpn_parent_child_handler:2633 child fd error! close fd [17]. In this log example, the sslvpnd process is trying to open a certificate named ‘root_certificate.cer’ and the private key file ‘root_certificate.key’.  However, the .key file cannot be opened. To verify if the .key file is missing use the command: fnsysctl ls /etc/cert/local/ This issue is usually caused by the configuration being copied from another FortiGate. To correct the CPU issue, change the certificate used for SSL VPN to any other certificate, Fortinet_Factory, for example. In the GUI, the SSL VPN certificate is configured under VPN -> SSL VPN Settings -> Server Certificate and select a certificate. Delete the certificate with the missing file. In the GUI, the certificates are found under System -> Certificates, select the certificate and delete it. From the CLI the certificate can be deleted with the following commands: config vpn certificate local     delete  <certificate name> end The proper certificate can now be uploaded and SSL VPN can be configured to use the certificate. For more information on uploading a certificate see: Technical Tip: FortiGate HTTPS/SSL Certificate Installation (PFX, PKCS12 and PEM)
