Troubleshooting Tip: Windows Agent 2FA manual token key in failed to login

[simonz_FTNT]

Description	This article describes how to troubleshoot Windows Agent with 2FA manual token authentication error with no issue using Push Token.
Scope	FortiAuthenticator Windows Agent.
Solution	When performing simulation using the FortiAuthenticator Agent Configuration tool with manual OTP token and getting the below error under the message box: Verification of user (labuser) OTP failed: VerifyOTP for user labuser failed: 401 Unauthorized First, check the log file under C:\Program Files\Fortinet\FortiAuthenticator Agent\log with the name FAC_Agent.Service.ServiceHost_log will able to give more context information on the failure, in this case, observe the below error: 2024-12-21 12:56:39,918 [4652|  15|DEBUG] FAC_Agent.Service.Impl: Processing LoginRequest for: labuser in session: 0 reason: Login 2024-12-21 12:56:39,918 [4652|  15|DEBUG] TwoFactorAuthPlugin: Received domain: SYDAD, username: labuser 2024-12-21 12:56:39,918 [4652|  15|DEBUG] TwoFactorAuthPlugin: Attempting authentication for labuser 2024-12-21 12:56:39,918 [4652|  15|DEBUG] TwoFactorAuthenticator: Authenticate input pars: subj name: FAC-VM0A12xxxxxx, host: 10.56.244.176:443, nretries: 3,  timeout: 5, allow_on_fail: Block, verifycert: False, certfile: C:\Program Files\Fortinet\fortinet_ca.crt, admin name: rest_user, Preferred Server 2024-12-21 12:56:39,918 [4652|  15|DEBUG] RestAPI: Initializing RestApi hostname: FAC-VM0A12xxxxxx, host: 10.56.xxx.xxx:443, verifyCert: False, admin: rest_user 2024-12-21 12:56:39,918 [4652|  43|DEBUG] RestAPI: Calling (REALMAUTH) 2024-12-21 12:56:39,981 [4652|  15|DEBUG] RestAPI: VerifyOTP for user labuserfailed: 401 Unauthorized 2024-12-21 12:56:39,981 [4652|  15|DEBUG] TwoFactorAuthenticator: Verification of user (labuser) OTP failed: VerifyOTP for user labuser failed: 401 Unauthorized 2024-12-21 12:56:39,981 [4652|  15|ERROR] PluginDriver: Failed to authenticate labuser, Message: Verification of user (labuser) OTP failed: VerifyOTP for user labuser failed: 401 Unauthorized From the log, the authentication process looks normal when it tries to authenticate labuser with FortiAuthenticator via Rest API but it gets '401 Unauthorized'. This error does refer to the permission issue, which should focus on the Rest API user account. Make sure the Rest API user account User Role has Full Permission selected as shown in the below screenshot and do not use a pre-defined or custom admin profile as this will create the above issue. Refer to this article if getting a 403 Forbidden error: Troubleshooting Tip: Troubleshooting '403 Forbidden' Errors in FortiAuthenticator Agent for Windows ...
