Technical Tip: How to monitor a Linux machine with SNMPv2

[mbenvenuti]

Description	This article describes how to monitor a Linux machine with SNMPv2.
Scope	FortiSIEM.
Solution	The next steps show how to configure the monitoring on a Linux device with SNMPv2. The following configuration is basic and has to be customized to the needs. Make sure that SNMP packages are installed. From Red-hat Linux-based machines as root: yum install -y net-snmp net-snmp-libs net-snmp-utils From Debian Linux based machines as root: apt-get install snmpd snmp Make a copy of the default configuration. cp /etc/snmp/snmpd.conf /etc/snmp/snmpd.conf.bak Create a specific SNMP configuration. The suggested configuration is basic but can obviously be customized, change 'myCommunity' with the desired community name. echo 'com2sec allConfig default myCommunity' > /etc/snmp/snmpd.conf echo 'group allConfigGroup v2c allConfig' >> /etc/snmp/snmpd.conf echo 'view allView included .1' >> /etc/snmp/snmpd.conf echo 'access allConfigGroup "" any noauth exact allView none none' >> /etc/snmp/snmpd.conf Activate snmpd service. systemctl restart snmpd systemctl enable snmpd Check snmpd service. Now it is possible to check that snmpd is running properly and retrieve some data: For memory info : snmpwalk -v 2c -c myCommunity -O e localhost UCD-SNMP-MIB::memory For CPU info: snmpwalk -v 2c -c myCommunity -O e localhost UCD-SNMP-MIB::systemStats Monitor the node. Run the discovery on the node. Go to Admin -> Setup -> Credentials -> 'Step 1: Enter Credentials' -> New and set Access Protocol: SNMP and previous community name chosen then save. Then associate the IP in 'Step 2: Enter IP Range to Credential Associations'. Create a new entry at Admin -> Setup -> Discovery and run the discovery. Finally, in Admin -> Setup -> Monitoring Performance, it is possible to edit the desired type of information to monitor. Tip: To see the events collected, it is possible to run a query in analytics with filter 'Event Type' containing PH_DEV_MON and reporting ip = ip_of_your_machine.
