Technical Tip: Blocking connection to FortiManager / Bypass FortiManager acting as FDS

[_mribwan]

Description	This article describes that in some instances, FortiManager has issues providing correct license info from FDS. This article describes the easiest way to block FortiGate from connecting to FortiManager for FDS updates and connect directly to FDS without changing the FortiManager config.
Scope	FortiGate, FortiManager.
Solution	To check the license status of managed FortiGate on FortiManager, run the following on FortiManager: diag fmupdate dbcontract FGTXXX (Replace 'FGTXXX' with the managed FortiGate Serial Number). Ensure include-default-servers is set to enable under config system central-management (it is enabled by default). This is to allow FortiGate to connect to FDS if the connection to FortiManager fails. Create a blackhole route to the FortiManager IP as such : config router static     edit 1         set dst 10.4.5.245 255.255.255.255         set blackhole enable         set vrf 0     next end Do note the usage of /32 as it is only desired to block the route to FortiManager. To verify, check the FortiGate connection status on FortiManager, or run the following commands on CLI, it should connect to FDS now.  diagnose debug application update -1 diagnose debug enable execute update-now To stop the debug, run the command 'diagnose debug disable'. Once the FortiManager issue is fixed, simply remove the static route created to re-instate the connection to FortiManager. config router static     delete 1 end
