Strange GUI Behavior

[Mitchell_Vitasys]

In our FortiManager and FortiAnalyzer we have some weird behavior with the UI elements.

Some hitboxed have a hitbox over the button. So we cant use these button without fiddling around with F12-DevMode. This happend on all browsers (Chrome, Edge, Firefox and even iExplorer) and on Phone and Desktop.

Is there something im missing to fix this or need i to create a new VirtualAppliance for the FAZ and FMG?

[AEK · Accepted solution]

Which versions?

[Mitchell_Vitasys]

There where both at 7.2.2.

I have updated them to 7.4.2.

Now the artifacts in the GUI are gone.

I suspect we had some corruption in the image.

[smkml]

Hi @Mitchell_Vitasys ,

This is affected on Chrome & Edge browser if you are in below version  6.4.12, 7.0.8, 7.2.3, or 7.4.1, you may refer the CS Bulletin below:


https://support.fortinet.com/Information/Bulletin.aspx

Customer Support Bulletin CSB-230607-1
FortiManager & FortiAnalyzer Web UI object failure after Chrome & Edge browser upgrade
