Technical Tip: How to fetch FortiAP and FortiSwitch Serials using TCL Script in FortiManager

farhanahmed · ‎04-02-2024

Description

This article describes how to use TCL script in FortiManager to fetch serial numbers of FortiAPs and FortiSwitches connected to FortiGate(s).

Scope

FortiManager, FortiGate.

Solution

Follow the initial steps from this article on how to enable and run TCL scripts in FortiManager:

Technical Tip: How to use TCL script...existing route

Go to Device Manager -> Scripts, select type TCL Script, and select 'Create new'.

Create the following TCL script:

#!
proc do_cmd {cmd} {
puts [exec "$cmd\n" "# "]
}
puts "FAPs connector this FGT:"
#
# Taking the output of the command in quotations
#
foreach line [split [exec "show wireless-controller wtp\n" "# "] \n] {
#
# Fetching the 'edit' and its value, that is, the serial number of FAP
#
if {[regexp {edit[ ]+"(\w+)"} $line match fap]} {
puts "$fap"
}
}
puts ""
puts "FSWs connector this FGT:"
#
# Taking the output of the command in quotations
#
foreach line [split [exec "show switch-controller managed-switch\n" "# "] \n] {
#
# Fetching the 'edit' and its value, that is, the serial number of FSW
#
if {[regexp {edit[ ]"(\w{16})} $line match fsw]} {
puts "$fsw"
}
}

After the script runs successfully, select View Details:

Select the execution history icon for each FortiGate:

This will show the details of the FortiAP and FortiSwitches connected to the FortiGate:

Check the FortiAP and FortiSwitches on the FortiGate for Verification:

Note:
In FortiManager, if FortiSwitch Manager and AP Manager are being used, the Export to Excel option can be used to get the list of the devices:
Importing and exporting FortiSwitch devices.
Importing and exporting FortiAP devices.
