Troubleshooting Tip: P1_Retransmit of IPsec tunnel with pfSense

[mle2802]

Description	This article describes one of the possible reasons for a P1_Retransmit of an IPsec tunnel with pfSense.
Scope	FortiGate and pfSense.
Solution	When creating a site-to-site IPsec tunnel with a pfSense firewall, the phase 1 and IKE debug return the following error: Run the following debugs to observe the output: diagnose vpn ike log-filter clear diagnose vpn ike log-filter dst-addr4 <ip_of_remote_end> diagnose debug application ike -1 diagnose debug enable Note: The command diagnose vpn ike log-filter dst-addr4 was changed to diagnose vpn ike log filter rem-addr4 starting from FortiOS version 7.4.1. On FortiOS version 7.4.1 or above, use rem-addr4 instead of dst-addr4. This change was made to update the command syntax for filtering IKE logs by the remote address. sent IKE msg (ident_i3send): <ip_of_fgt>:4500-><ip_of_remote_end>:4500, len=108, id=14961d6d3f16486a/3f553c6066e91fac ike 0: comes <ip_of_remote_end>:500-><ip_of_fgt>:500,ifindex=8.... ike 0: IKEv1 exchange=Informational id=14961d6d3f16486a/3f553c6066e91fac:51da3eaa len=76 ike 0: in 14961D6D3F16486A3F553C6066E91FAC0810050151DA3EAA0000004C25E6CBBC380CCB26039353B6C 960C8F3EB3A39226208E8317DF8F8C6C0E44CF01E0A2850C991F25A53A182CAEC13A495 ike 0:fil_e2-dat_e1:370438: dec 14961D6D3F16486A3F553C6066E91FAC0810050151DA3EAA0000004C1CF5C 5E69CF0D37883BCF8835E869E3B0C3FB82632241ADD6C943C1CE824C0373485524F1E63EA0CFFC1BB092D0F7B7D ike 0:fil_e2-dat_e1:370440: out B877B4A9173E298A8596BD5F7895EDA305100201000000000000006C5FF7595E 87F64F43BC2E1B3226F1FF46E5A 793DE83FE29C4EF696F0FD90120A2A9E11498A64D845CC9BBC48ED3ADB1D8C0C06353DA176278D9799DF5D61595AF2CEB 5F7737257DD293A20409E92BE49F ike 0:fil_e2-dat_e1:370440: sent IKE msg (P1_RETRANSMIT): <ip_of_fgt>:4500-><ip_of_remote_end>:4500, len=108, id=b877b4a9173e298a/8596bd5f7895eda3 ike 0: comes <ip_of_remote_end>:500-><ip_of_fgt>:500,ifindex=8.... ike 0: IKEv1 exchange=Informational id=b877b4a9173e298a/8596bd5f7895eda3:b2ceacff len=76 ike 0: in B877B4A9173E298A8596BD5F7895EDA308100501B2CEACFF0000004CCB36F2BBBBA0B1EB465A94AD5B3C347CF 5719D40CD 84EDC1F89F2B8A518FF5753DBF071BAEBF7E8C7AA64DDFA7B68C28 ike 0:fil_e2-dat_e1:370440: dec B877B4A9173E298A8596BD5F7895EDA308100501B2CEACFF0000004C690B44395B1CCA084B8C0A9E0DBF58D40264AF8777 D14A8A9B738D985820CB60E70445BA106B2CE01E97F069B559A7A0 To stop the debugs: diagnose debug disable diagnose debug reset This is because FortiGate is behind a NAT device with a private IP on a WAN interface. This does not match on the pfSense side. To fix this, change the 'Peer identifier' on pfSense to 'IP address' and specify the private IP on the WAN interface of FortiGate. Related document: pfSense documentation on IPsec VPN configuration
