Troubleshoot Tip: Filter files with watermarked when those are sent over secure websites

JordAnge · ‎05-30-2023

Description

This article describes how to filter files with watermarked when those are sent over secure websites.

Relate document:

https://docs.fortinet.com/document/fortigate/6.2.0/cookbook/581444/dlp-watermarking

Scope

FortiGate v7.0.9.

Solution

Topology:

LAN-User ===> FGT ===| Internet (Gmail)

1) Follow the link mentioned above to apply a watermark over the file to block.

2) Be sure the firewall policy works in 'proxy-mode' (set inspection-mode proxy).

3) DLP-Sensor works in the website (by URL or category) is under inspection (Monitor).

4) Be sure to configure deep-inspection over firewall policy.

Example CLI:

config dlp sensor

edit "delfa"

set feature-set proxy

config filter

edit 1

set name "DELFA_DLP"

set proto smtp pop3 imap http-get http-post ftp nntp mapi ssh cifs

set filter-by watermark

set company-identifier "DELFA_DLP"

set sensitivity "Critical"

set archive enable

set action block

config webfilter urlfilter

edit 10

config entries

edit 1

set url "*.delfa.com.br/*"

set type wildcard

set action monitor

set url "*mail.google.com*"

set type wildcard

set action monitor

config webfilter profile

edit "Clone_WF_TI"

config web

set urlfilter-table 10

end

config firewall policy

edit 1

set name "Proxy_rule_dlp"

set srcintf "port3"

set dstintf "virtual-wan-link"

set action accept

set srcaddr "all"

set dstaddr "all"

set schedule "always"

set service "ALL"

set utm-status enable

set inspection-mode proxy

set ssl-ssh-profile "custom-deep-inspection"

set webfilter-profile "Clone_WF_TI"

set dlp-sensor "delfa"
