This article provides a step-by-step guide to configure a ZTNA agentless web portal using SAML authentication with Entra ID as the Identity Provider (IDP) . This enhanced ZTNA web portal allows access to protected resources using only a client browser.
The Entra ID enterprise application should be configured previously by including the FortiGate 'Service Provider' (SP) URLs ('http://ztna.fortilab.local:2587/xxxx'). The Entra ID SAML certificate should be downloaded and imported into the FortiGate Remote certificate store. The imported certificate can be renamed to maintain a clean and consistent configuration:
config vpn certificate remote
rename Remote_Cert_1 to saml-ztna-entra
end
The SSL server certificate 'ztna.fortilab.local' was previously imported to FortiGate (Technical Tip: FortiGate HTTPS/SSL Certificate Installation (PFX, PKCS12, PEM and CER)).
- Configure the FortiGate SAML server according to the Entra ID 'Identity Provider' (IdP) settings (IdP URLs and username/group attribute name):
config user saml
edit "saml-ztna"
set cert "ztna.fortilab.local"
set entity-id "http://ztna.fortilab.local:2587/remote/saml/metadata/"
set single-sign-on-url "https://ztna.fortilab.local:2587/remote/saml/login"
set single-logout-url "https://ztna.fortilab.local:2587/remote/saml/logout"
set idp-entity-id "https://sts.windows.net/xxxxxx/"
set idp-single-sign-on-url "https://login.microsoftonline.com/xxxxxx/saml2"
set idp-single-logout-url "https://login.microsoftonline.com/xxxxxx/saml2"
set idp-cert "saml-ztna-entra"
set user-name "name"
set group-name "groups"
set digest-method sha1
next
end
-
Create a user group for ZTNA with SAML authentication. The group name 'xxxxxxxxxxxx' is the Object ID obtained from the Azure portal for the allowed group.
config user group
edit "saml-ztna"
set member "saml-ztna"
config match
edit 1
set server-name "saml-ztna"
set group-name "xxxxxxxxxxxx"
next
end
next
end
-
Set up the VIP for the ZTNA agentless access:
config firewall vip
edit "ZTNA-agentless"
set type access-proxy
set server-type https
set extip 10.5.147.78
set extintf "port1"
set client-cert disable
set extport 2587
set ssl-certificate "ztna.fortilab.local"
next
end
-
Define the virtual host for the web portal:
config firewall access-proxy-virtual-host
edit "ztna-web-portal-fqdn"
set ssl-certificate "ztna.fortilab.local"
set host "ztna.fortilab.local"
set client-cert disable
next
end
-
Create an authentication scheme using the SAML method and assign the previously configured SAML server:
config authentication scheme
edit "ztna-web-portal-saml"
set method saml
set saml-server "saml-ztna"
next
end
-
Configure the authentication rule, using the SAML method scheme:
config authentication rule
edit "ztna-web-portal-rule"
set protocol ztna-portal
set ip-based disable
set active-auth-method "ztna-web-portal-saml"
set web-auth-cookie enable
next
end
-
Configure the ZTNA web portal using the previously configured firewall vip, access-proxy-virtual-host, and authentication rule:
config ztna web-portal
edit "ztna-web-portal"
set vip "ZTNA-agentless"
set host "ztna-web-portal-fqdn"
set auth-rule "ztna-web-portal-rule"
next
end
-
Create bookmarks for the ZTNA web portal (this example is for an RDP connection to 10.15.19.81).
config ztna web-portal-bookmark
edit "bookmarks"
set groups "saml-ztna"
config bookmarks
edit "rdp"
set apptype rdp
set host "10.15.19.81"
set port 3389
next
end
next
end
-
Set up the proxy policy for the ZTNA web portal:
config firewall proxy-policy
edit 0
set name "ZTNA-web-portal"
set proxy ztna-proxy
set ztna-proxy "ztna-web-portal"
set srcintf "any"
set srcaddr "all"
set dstaddr "all"
set action accept
set schedule "always"
set logtraffic all
next
end
The remote client should navigate to 'https://ztna.fortilab.local:2587', select the 'Login' button on the web portal, and authenticate via the Microsoft login page. Once authenticated, access to the ZTNA agentless web portal with pre-configured bookmarks will be available.
Use the following FortiGate CLI command to verify the user authentication:
diagnose wad user list
ID: 6, VDOM: root, IPv4: 10.5.147.84
user name : user1@fortilab.onmicrosoft.com
worker : 0
duration : 3
auth_type : Session
auth_method : SAML
pol_id : 0
g_id : 0
user_based : 0
expire : no
LAN:
bytes_in=3945 bytes_out=1170959
WAN:
bytes_in=0 bytes_out=0
Notes:
For 'apptype web' to function, the FQDN must be defined under 'config ztna web-portal-bookmark'.
- The FortiGate must be able to resolve the FQDN to the internal web server IP address.
- The client workstation must resolve the same FQDN to the FortiGate external IP address used for ZTNA access (modifying the Windows Hosts file may be required).
Configuration example:
config ztna web-portal-bookmark
edit "bookmarks"
set groups "saml-ztna"
config bookmarks
edit "URL_HTTPS"
set url "https://example.com"
next
end
next
end
