Technical Tip: Understanding and configuring BGP security feature 'set enforce-first-as'.

[shahrukh_khan]

Description	This article describes FortiGate's BGP configuration 'set enforce-first-as' is a security feature that helps prevent BGP route leaks and AS_PATH spoofing.
Scope	FortiGate.
Solution	When 'set enforce-first-as' is enabled, FortiGate checks incoming BGP UPDATE messages from eBGP peers. The leftmost (first) AS number in the AS_PATH attribute must match the configured remote-as of the sending peer. If it matches: The update is processed normally. If it mismatches: The update is rejected, and FortiGate logs an error like 'Incorrect leftmost AS number'. It may also send a BGP NOTIFICATION (error code 3/11: Malformed AS_PATH). This prevents scenarios where malicious or misconfigured peers inject routes with spoofed AS paths. Default behavior: Enabled in FortiOS v6.2+. Configuration: config router bgp     set as <local-as>     set router-id <router-id>     set enforce-first-as enable         config neighbor             edit "<peer-ip>"                 set remote-as <peer-as>                 ... (other settings)             next         end end Disable (For route server or special cases): config router bgp     set enforce-first-as disable end After changing, clear the affected BGP sessions: execute router clear bgp all Or for a specific neighbor: execute router clear bgp ip <neighbor-ip> Verification and debugging: get router info bgp summary get router info bgp neighbors <peer-ip> received routes diagnose ip router bgp all enable diagnose ip router bgp level info diagnose debug enable Debug: Violation Occurs (enforce-first-as enabled): BGP: 10.68.15.2-Outgoing [DECODE] Update: Starting UPDATE decoding... BGP: 10.68.15.2-Outgoing [DECODE] **Attr ASPATH: Incorrect leftmost AS number, should be 273412** BGP: 10.68.15.2-Outgoing [FSM] State: Established Event: 27 BGP: %BGP-3-NOTIFICATION: sending to 10.68.15.2 3/11 (UPDATE Message Error/Malformed AS_PATH.) BGP: %BGP-5-ADJCHANGE: neighbor 10.68.15.2 Down BGP Notification
