Troubleshooting Tip: Token prompt not received for IPsec dial-up VPN and EAP password failure error received

[js2]

Description	This article describes a use case where, after enabling IKEv2, the user authentication fails with the error 'EAP password failure'.
Scope	FortiGate, FortiAuthenticator.
Solution	In this use case, the setup works as expected with PAP using IKEv1. However, in IKEv2, MS-CHAP will be used. Debugs to be checked: FortiClient debug: Log Level-->Debug IPsec debug from FortiGate: diagnose vpn ike log filter rem-addr4 <remote_side_publicIP> diagnose debug application ike -1 diagnose debug application fnbamd -1 diagnose debug application eap_proxy -1 diagnose debug enable To disable the debug after testing: diagnose debug disable diagnose vpn ike log filter clear diagnose debug reset FortiAuthenticator debug: https://<FAC IP>/debug/radius/  From FortiAuthenticator debug, it is observed challenge message is sent, but no response is received. In the user PC, an EAP password error is received. 2026-01-02T03:47:22.824653-08:00 FortiAuthenticator radiusd[30624]: (4) eap: EAP session adding &reply:State = 0x22a6ecd322a7eaff 2026-01-02T03:47:22.824656-08:00 FortiAuthenticator radiusd[30624]: (4)     [eap] = handled 2026-01-02T03:47:22.824659-08:00 FortiAuthenticator radiusd[30624]: (4)   } # authenticate = handled 2026-01-02T03:47:22.824666-08:00 FortiAuthenticator radiusd[30624]: (4) Using Post-Auth-Type Challenge 2026-01-02T03:47:22.824674-08:00 FortiAuthenticator radiusd[30624]: (4) # Executing group from file /usr/etc/raddb/sites-enabled/default 2026-01-02T03:47:22.824677-08:00 FortiAuthenticator radiusd[30624]: (4)   Challenge { ... } # empty sub-section is ignored 2026-01-02T03:47:22.824691-08:00 FortiAuthenticator radiusd[30624]: (4) Sent Access-Challenge Id 55 from 0.0.0.0:2083 to 10.103.195.177:32982 length 73 2026-01-02T03:47:22.824694-08:00 FortiAuthenticator radiusd[30624]: (4)   EAP-Message = 0x0101000f0650617373776f72643a20 2026-01-02T03:47:22.824697-08:00 FortiAuthenticator radiusd[30624]: (4)   Message-Authenticator = 0x00000000000000000000000000000000 2026-01-02T03:47:22.824700-08:00 FortiAuthenticator radiusd[30624]: (4)   State = 0x22a6ecd322a7eaff47a4e2b3faa55d19 2026-01-02T03:47:22.824720-08:00 FortiAuthenticator radiusd[30624]: (0) (TLS) send TLS 1.3 Handshake, Finished 2026-01-02T03:47:22.824755-08:00 FortiAuthenticator radiusd[30624]: (4) Finished request Solution: Ensure EAP is enabled in the RADIUS policy and the EMS server. In the RADIUS policy, under Advanced Options, enable 'Allow OTP for EAP-MSCHAPv2 Authentication with FortiClient'.
