Question

[SD-WAN] configure SD-WAN for an IPSEC Tunnel and a local radio link

  • February 19, 2025
  • 2 replies
  • 1285 views

Good day, my name is gafar.



I have a case in my office, which is to setup SD-WAN between two Fortigate site office and Head Office (HO). we use two links, one is a local radio link via connection provider (L2) and another one is through IPsec Tunnel via internet (Starlink). Can someone point me a guide for this? because i already tried the guide below, but it doesnt seems to fit the purpose, since one of the links are just a LAN.



Technical-Tip-Configure-IPsec-VPN-with-SD-WAN



Also, kinda confused with the local and remote address in ipsec sdwan, should we create all the IP subnet in the routing table as a remote address in ipsec configuration?



below i attach the simple topology.









topology SDWAN Ipsec.png



Thanks before.



Gafar.



2 replies

Stephen_G
Moderator
Stephen_G
Moderator
February 21, 2025

Hello,


Thank you for using the Community Forum. I will seek to get you an answer or help. We will reply to this thread with an update as soon as possible.


Thanks,

Stephen_G - Fortinet Community Team
Fab-S
Fab-S
New Member
February 23, 2025

Hi Gafar,



Did you see this link:

https://docs.fortinet.com/document/fortigate/7.4.1/administration-guide/402352/network-topologies
I guess you should find what you're looking for....

Otherwise, find below a very basic site-to-site IPsec configuration that you could fine tune regarding your needs.

config vpn ipsec phase1-interface

    edit "Tun0"

        set interface "port2"

        set ike-version 2

        set peertype any

        set net-device disable

        set proposal des-sha1

        set dhgrp 14

        set nattraversal disable

        set remote-gw 210.0.X.X

        set psksecret ENC xxxxxxx

    next

…….

config vpn ipsec phase2-interface

    edit "Tun0"

        set phase1name "Tun0"

        set proposal des-md5 des-sha1

    next



Regards

    Fab-S
    Fab-S
    New Member
    February 23, 2025

    After that, you have to add your IPsec Interface as a member and create a zone in which you place your members (IPsec interface and other).
    This second step is described here: https://docs.fortinet.com/document/fortigate/7.4.1/administration-guide/942095
