No internet connection on the machine connected to LAN network
Hello Team,
Please help me to trouble shoot on the below issue
I have fortinet firewall VM (FortiOS v6.4.15 build2095 (GA)) setup, there two active ports WAN and LAN.
I have connected to a system to my LAN network, the system is assigned with an IP (70.10.10.2) coming from the Fortinet LAN interface, but not getting the internet connection or not able to ping 8.8.8.8 though i have created the policy to route through WAN.
i am sharing below, the debug comments i used and the result i got from it. pls help me on this.
FortiOS-FW-01 # diagnose debug disable
FortiOS-FW-01 # diagnose debug reset
FortiOS-FW-01 # diagnose debug flow filter saddr 70.10.10.2
FortiOS-FW-01 # diagnose debug flow filter daddr 8.8.8.8
FortiOS-FW-01 # diagnose debug flow filter proto 1
FortiOS-FW-01 # diagnose debug flow trace start 100
FortiOS-FW-01 # diagnose debug enable
FortiOS-FW-01 # id=20085 trace_id=3 func=print_pkt_detail line=5822 msg="vd-root:0 received a packet(proto=1, 70.10.1
0.2:1->8.8.8.8:2048) from port3. type=8, code=0, id=1, seq=4388."
id=20085 trace_id=3 func=init_ip_session_common line=5993 msg="allocate a new session-00008e9a"
id=20085 trace_id=3 func=vf_ip_route_input_common line=2615 msg="find a route: flag=04000000 gw-192.168.1.1 via port2
"
id=20085 trace_id=4 func=print_pkt_detail line=5822 msg="vd-root:0 received a packet(proto=1, 70.10.10.2:1->8.8.8.8:2
048) from port3. type=8, code=0, id=1, seq=4389."
id=20085 trace_id=4 func=init_ip_session_common line=5993 msg="allocate a new session-00008e9b"
id=20085 trace_id=4 func=vf_ip_route_input_common line=2615 msg="find a route: flag=04000000 gw-192.168.1.1 via port2
"
id=20085 trace_id=5 func=print_pkt_detail line=5822 msg="vd-root:0 received a packet(proto=1, 70.10.10.2:1->8.8.8.8:2
048) from port3. type=8, code=0, id=1, seq=4390."
id=20085 trace_id=5 func=init_ip_session_common line=5993 msg="allocate a new session-00008e9e"
id=20085 trace_id=5 func=vf_ip_route_input_common line=2615 msg="find a route: flag=04000000 gw-192.168.1.1 via port2
"
id=20085 trace_id=6 func=print_pkt_detail line=5822 msg="vd-root:0 received a packet(proto=1, 70.10.10.2:1->8.8.8.8:2
048) from port3. type=8, code=0, id=1, seq=4391."
id=20085 trace_id=6 func=init_ip_session_common line=5993 msg="allocate a new session-00008ea2"
id=20085 trace_id=6 func=vf_ip_route_input_common line=2615 msg="find a route: flag=04000000 gw-192.168.1.1 via port2
