Fortigate NAT Use Dynamic IP Pool with 2 service providers

Greetings,

This document will help you to associate the IPpool in case where you have two different wan connections, https://community.fortinet.com/t5/FortiGate/Technical-Tip-How-to-associate-a-NAT-pool-IP-pool-to-a-physical/ta-p/189738

config firewall ippool
    edit <IP_Pool_1>
        set associated-interface <port wan1>
    next
    edit <IP_Pool_2>
        set associated-interface <port wan2>
    next
end

Regards!

If you have found a solution, please like and accept it to make it easily accessible for others.

Hi @sg32 ,

You may also try with Central SNAT:

https://docs.fortinet.com/document/fortigate/7.4.6/administration-guide/421028/central-snat

I have an issues with Session Clashes.

//Diag message

Fortigate01 # diag sys session stat
misc info: session_count=268953 setup_rate=1916 exp_count=15 reflect_count=0 clash=64960661
memory_tension_drop=0 ephemeral=0/3211264 removeable=0 extreme_low_mem=0
npu_session_count=103007
nturbo_session_count=102950
delete=2497, flush=2, dev_down=75/304
session walkers: active=0, vf-277, dev-74, saddr-0, npu-0, wildcard-0
TCP sessions:
15 in NONE state
74409 in ESTABLISHED state
153 in SYN_SENT state
21 in SYN_RECV state
126 in FIN_WAIT state
1148 in TIME_WAIT state
3858 in CLOSE state
2301 in CLOSE_WAIT state
firewall error stat:
error1=00000000
error2=00000000
error3=00000000
error4=00000000
tt=00000000
cont=00000008
ips_recv=100d071e
policy_deny=01514ab5
av_recv=00000d8a
fqdn_count=00000014
fqdn6_count=00000003
global: ses_limit=0 ses6_limit=0 rt_limit=0 rt6_limit=0

//End

Im pretty sure it is only a dns and secure dns problem.

The clash details do not state which protocol is causing the issue UDP or TCP.   I read https://community.fortinet.com/t5/FortiGate/Technical-Tip-Avoid-NAT-port-exhaustion/ta-p/321941

and this document states that i should lower the TTL for DNS.

What should I do?
