Fortigate DNAT issue - Applied to all traffic regardless of filter

Below is the icmp flow debug output.

FortiGate-VM64 # id=20085 trace_id=24 func=print_pkt_detail line=5320 msg="vd-root:0 received a packet(proto=1, 136.0.0.11:11->10.123.11.11:2048) from port2. type=8, code=0, id=11, seq=0."
id=20085 trace_id=24 func=init_ip_session_common line=5480 msg="allocate a new session-00008148"
id=20085 trace_id=24 func=vf_ip_route_input_common line=2590 msg="find a route: flag=00000000 gw-10.123.11.11 via port3"
id=20085 trace_id=24 func=fw_forward_handler line=749 msg="Allowed by Policy-2: SNAT"
id=20085 trace_id=24 func=__ip_session_run_tuple line=3226 msg="SNAT 136.0.0.11->10.123.123.11:11"
id=20085 trace_id=25 func=print_pkt_detail line=5320 msg="vd-root:0 received a packet(proto=1, 10.123.11.11:11->10.123.123.11:0) from port3. type=0, code=0, id=11, seq=0."
id=20085 trace_id=25 func=resolve_ip_tuple_fast line=5395 msg="Find an existing session, id-00008148, reply direction"
id=20085 trace_id=25 func=__ip_session_run_tuple line=3240 msg="DNAT 10.123.123.11:0->136.0.0.11:11"
id=20085 trace_id=25 func=vf_ip_route_input_common line=2590 msg="find a route: flag=04000000 gw-10.123.10.10 via port2"

[size="2"][size="2"] Below are the configurations that may be needed[/size][/size]

FortiGate-VM64 # show firewall policy
config firewall policy
 edit 1
 set name "123"
 set uuid e4d8930a-7897-51e8-0b6d-2608bf493342
 set srcintf "any"
 set dstintf "any"
 set srcaddr "all"
 set dstaddr "swscan.apple.com"
 set action accept
 set schedule "always"
 set service "ALL"
 next
 edit 2
 set name "ping test"
 set uuid a89be098-78d5-51e8-213f-b62a721b6d61
 set srcintf "any"
 set dstintf "any"
 set srcaddr "all"
 set dstaddr "all"
 set action accept
 set schedule "always"
 set service "ALL_ICMP"
 set logtraffic all
 next
end

FortiGate-VM64 # show firewall vip
config firewall vip
 edit "IBZ-Server-to-136"
 set uuid 2e8205be-7941-51e8-85d9-a7a3b463c25d
 set src-filter "10.123.11.10/32"
 set extip 10.123.123.0-10.123.123.255
 set extintf "port2"
 set nat-source-vip enable
 set srcintf-filter "port3"
 set mappedip "136.0.0.0-136.0.0.255"
 next
end

FortiGate-VM64 # show firewall central-snat-map
config firewall central-snat-map
 edit 1
 set orig-addr "OUT"
 set srcintf "any"
 set dst-addr "IBZ1"
 set dstintf "any"
 set nat-ippool "GW-IP-IBZ1"
 next
 edit 2
 set orig-addr "136"
 set srcintf "port2"
 set dst-addr "all"
 set dstintf "port3"
 set nat disable
 next
end

FortiGate-VM64 # show firewall address 136
config firewall address
 edit "136"
 set uuid 65d67122-78dc-51e8-3d65-89f6349f5c4b
 set subnet 136.0.0.0 255.255.255.0
 next
end

FortiGate-VM64 # show firewall address OUT
config firewall address
 edit "OUT"
 set uuid bdc42078-78d7-51e8-80ee-d219bd45f314
 set subnet 10.123.10.0 255.255.255.0
 next
end

FortiGate-VM64 # show firewall address IBZ1
config firewall address
 edit "IBZ1"
 set uuid cb5b31cc-78d7-51e8-041d-80282e80612d
 set subnet 10.123.11.0 255.255.255.0
 next
end

[size="2"] [/size]

[size="2"]I have contacted TAC and they also verified that there is some issue with the DNAT. Will update their response once i hear from them.[/size]

[size="2"]Thanks[/size]

thanks all for the reply.

I contacted TAC and they tested the sme in production.

Got reply after almost 20 days that its a known bug. Below is the exact response.

"Thank you for your patience. I have learnt from the case description that the traffic initiated from the internal server are translated to VIP External IP address although the Central SNAT is enabled. Please correct me, if I am wrong. I did an internal search found it to be an known issue on the firmware version 6.0.1 which is reported already to our engineering team against the bug#478681 and they are working on the fix. In the meantime, We could consider downgrading the firmware on the unit to 5.6.4(i.e. latest in the 5.6 series) or 5.4.8(i.e. latest in the 5.4 series) as a workaround. I will get back to you once the fix is available. "

Thanks

san
