FortiSOAR Custom Dashboard

Hi,

You can create a custom module in FortiSOAR and save data created by playbook in it.  You can use this module records  as input data for appropriate widgets   in a dashboard.

Perhaps it would be more helpful if I explained what it is that I'm trying to do here. I currently have a script that pulls JSON data from an endpoint running every hour. I want to take an integer value from that output and track the way it's trending for up to a week.

You can check https://docs.fortinet.com/document/fortisoar/7.3.0/administration-guide/97786/application-editor , section module editor . Using module editor , you can create a custom module to store data you need , which you can then use for creating dashboard.

The script you mentioned , what is output format ?  Can you tweak script to provide a output in CSV format where columns can be mapped to fields of module in FortiSOAR. The we can use CSV data management solution pack to ingest CSV file and update custom module.

In more advance way , we can make script send output data as a payload directly to FortiSOAR playbook which in turn can update module records.

I have also attached a redacted copy (credentials removed) of the playbook script that I run to extract this data in addition to the JSON output for the data I need to parse for the widgets.

The output contains a series of metrics for a list of servers. For each server I'd like to display the graphs mentioned above for the following metrics:
- cpu

- hp

- rp

- dup

Playbook:

{ "type": "workflow_collections", "data": [ { "@context": "/api/3/contexts/WorkflowCollection", "@type": "WorkflowCollection", "name": "001 - CSE Tests", "description": null, "visible": true, "image": null, "id": 64, "createDate": 1661333764.460715, "modifyDate": 1663983252.383072, "deletedAt": null, "importedBy": [], "recordTags": [], "workflows": [ { "@type": "Workflow", "triggerLimit": null, "name": "Test Elastic Node Stats", "aliasName": null, "tag": null, "description": null, "isActive": true, "debug": true, "singleRecordExecution": false, "remoteExecutableFlag": false, "parameters": [], "synchronous": false, "lastModifyDate": 1680036269, "collection": "/api/3/workflow_collections/f48521da-efbc-43b6-85bb-5c9ed5d851f4", "versions": [], "triggerStep": "/api/3/workflow_steps/ce02477b-a2ba-400b-9c49-c83658caf67b", "steps": [ { "@type": "WorkflowStep", "name": "Create Elastic Node Stats Record", "description": null, "arguments": { "resource": { "__replace": "", "dataSource": "{{vars.steps.Generate_Data_Source.data}}{{vars.steps.Generate_Data_Source.data['code_output']}}", "dataValueName": "{{vars.steps.Generate_Data_Value_Name.data['code_output']}}", "elasticNodeStatData": "{{vars.steps.Get_Elastic_Node_Stats.data['code_output']}}" }, "operation": "Overwrite", "collection": "/api/3/data_values", "__recommend": [], "fieldOperation": { "recordTags": "Overwrite" }, "step_variables": [] }, "status": null, "top": "40", "left": "1340", "stepType": "/api/3/workflow_step_types/2597053c-e718-44b4-8394-4d40fe26d357", "group": null, "uuid": "2a83730f-deec-4875-9b7e-c2d82f5698f1" }, { "@type": "WorkflowStep", "name": "Generate Data Value Name", "description": null, "arguments": { "config": "3f12d36a-b7c9-42c4-9620-4739b92b284a", "params": { "python_function": "print(\"Elastic Node Stats\")" }, "version": "2.0.3", "connector": "code-snippet", "operation": "python_inline_code_editor", "operationTitle": "Execute Python Code", "step_variables": [] }, "status": null, "top": "40", "left": "360", "stepType": "/api/3/workflow_step_types/1fdd14cc-d6b4-4335-a3af-ab49c8ed2fd8", "group": null, "uuid": "60c0d37f-1070-49b9-a072-7409745c2d59" }, { "@type": "WorkflowStep", "name": "Generate Data Source", "description": null, "arguments": { "config": "3f12d36a-b7c9-42c4-9620-4739b92b284a", "params": { "python_function": "print(\"Elastic Cat Nodes API\")" }, "version": "2.0.3", "connector": "code-snippet", "operation": "python_inline_code_editor", "operationTitle": "Execute Python Code", "step_variables": [] }, "status": null, "top": "40", "left": "680", "stepType": "/api/3/workflow_step_types/1fdd14cc-d6b4-4335-a3af-ab49c8ed2fd8", "group": null, "uuid": "8c88461c-4460-44e2-ab60-0680dea71b7d" }, { "@type": "WorkflowStep", "name": "Get Elastic Node Stats", "description": null, "arguments": { "config": "3f12d36a-b7c9-42c4-9620-4739b92b284a", "params": { "python_function": "import json\nimport requests\nfrom requests.structures import CaseInsensitiveDict\nimport time\n\napi_base_url = f\"https://api.endpoint.example.com\"\n\n# API version\nav = f\"v1\"\n\n# Service\nsvc = f\"_cat\"\n\n# Action\nact = f\"nodes?v&h=name,ip,role,master,cpu,rm,rc,rp,hm,hc,hp,dt,du,dup&s=node.role\"\n\nheaders = CaseInsensitiveDict()\n\nheaders[\"Accept\"] = \"application/json\"\n\nheaders[\"Authorization\"] = f\"Basic *****REDACTED*****\"\n\nendpoint = f\"{api_base_url}/{svc}/{act}\"\n\ntimestr = time.strftime(\"%Y-%m-%d_%H:%M:%S\")\n\nsr = requests.get(endpoint, headers=headers)\n\nsr_json = sr.json()\n\nprint(sr_json)" }, "version": "2.0.3", "connector": "code-snippet", "operation": "python_inline_code_editor", "operationTitle": "Execute Python Code", "step_variables": [] }, "status": null, "top": "40", "left": "1020", "stepType": "/api/3/workflow_step_types/1fdd14cc-d6b4-4335-a3af-ab49c8ed2fd8", "group": null, "uuid": "ae73f819-5b3f-489a-a4cc-5bd9915105e3" }, { "@type": "WorkflowStep", "name": "Start", "description": null, "arguments": { "route": "4f983a73-5c6e-47c3-a48e-ff74d4b3ba7c", "resources": [ "data_values" ], "inputVariables": [], "step_variables": { "input": { "params": [], "records": "{{vars.input.records}}" } }, "executeButtonText": "Execute", "noRecordExecution": true, "singleRecordExecution": false }, "status": null, "top": "40", "left": "40", "stepType": "/api/3/workflow_step_types/f414d039-bb0d-4e59-9c39-a8f1e880b18a", "group": null, "uuid": "ce02477b-a2ba-400b-9c49-c83658caf67b" } ], "routes": [ { "@type": "WorkflowRoute", "name": "Start -> Generate Data Value Name", "targetStep": "/api/3/workflow_steps/60c0d37f-1070-49b9-a072-7409745c2d59", "sourceStep": "/api/3/workflow_steps/ce02477b-a2ba-400b-9c49-c83658caf67b", "label": null, "isExecuted": false, "uuid": "f0c86d56-2fed-4452-8aea-a0239676cf6b" }, { "@type": "WorkflowRoute", "name": "Generate Data Value Name -> Generate Data Source", "targetStep": "/api/3/workflow_steps/8c88461c-4460-44e2-ab60-0680dea71b7d", "sourceStep": "/api/3/workflow_steps/60c0d37f-1070-49b9-a072-7409745c2d59", "label": null, "isExecuted": false, "uuid": "5eb5c03a-539e-4f32-848e-cda7afa4ebbb" }, { "@type": "WorkflowRoute", "name": "Generate Data Source -> Get Elastic Node Stats", "targetStep": "/api/3/workflow_steps/ae73f819-5b3f-489a-a4cc-5bd9915105e3", "sourceStep": "/api/3/workflow_steps/8c88461c-4460-44e2-ab60-0680dea71b7d", "label": null, "isExecuted": false, "uuid": "d4e22e4d-32ae-41d0-9878-edd903371b03" }, { "@type": "WorkflowRoute", "name": "Get Elastic Node Stats -> Create Elastic Node Stats Record", "targetStep": "/api/3/workflow_steps/2a83730f-deec-4875-9b7e-c2d82f5698f1", "sourceStep": "/api/3/workflow_steps/ae73f819-5b3f-489a-a4cc-5bd9915105e3", "label": null, "isExecuted": false, "uuid": "1b1f9d76-14ec-4386-8992-0e82f5c99ff2" } ], "groups": [], "priority": "/api/3/picklists/2b563c61-ae2c-41c0-a85a-c9709585e3f2", "uuid": "9b4815f1-1d45-45ec-b403-357192655c4b", "id": 1086, "owners": [], "isPrivate": false, "deletedAt": null, "importedBy": [], "recordTags": [] } ] } ], "exported_tags": [] }

Output:

{   "data": {     "code_output": [       {         "dt": "4.5tb",         "du": "4.4tb",         "hc": "21.6gb",         "hm": "30gb",         "hp": "72",         "ip": "172.27.209.249",         "rc": "52gb",         "rm": "60gb",         "rp": "87",         "cpu": "8",         "dup": "98.21",         "name": "instance-0000000093",         "role": "f",         "master": "-"       },       {         "dt": "4.3tb",         "du": "4.2tb",         "hc": "9.6gb",         "hm": "30gb",         "hp": "32",         "ip": "172.27.200.39",         "rc": "52.3gb",         "rm": "60gb",         "rp": "87",         "cpu": "33",         "dup": "97.81",         "name": "instance-0000000107",         "role": "f",         "master": "-"       },       {         "dt": "4.3tb",         "du": "4.2tb",         "hc": "19.2gb",         "hm": "30gb",         "hp": "64",         "ip": "172.27.211.192",         "rc": "52gb",         "rm": "60gb",         "rp": "87",         "cpu": "27",         "dup": "97.81",         "name": "instance-0000000108",         "role": "f",         "master": "-"       },       {         "dt": "4.5tb",         "du": "4.4tb",         "hc": "9gb",         "hm": "30gb",         "hp": "30",         "ip": "172.27.203.191",         "rc": "51.9gb",         "rm": "60gb",         "rp": "87",         "cpu": "7",         "dup": "98.22",         "name": "instance-0000000094",         "role": "f",         "master": "-"       },       {         "dt": "4.3tb",         "du": "4.2tb",         "hc": "14.4gb",         "hm": "30gb",         "hp": "48",         "ip": "172.27.101.171",         "rc": "52.3gb",         "rm": "60gb",         "rp": "87",         "cpu": "95",         "dup": "97.83",         "name": "instance-0000000099",         "role": "f",         "master": "-"       },       {         "dt": "1.7tb",         "du": "230.9gb",         "hc": "7.1gb",         "hm": "30gb",         "hp": "23",         "ip": "172.27.211.40",         "rc": "53.2gb",         "rm": "60gb",         "rp": "89",         "cpu": "8",         "dup": "13.10",         "name": "instance-0000000106",         "role": "hrst",         "master": "-"       },       {         "dt": "1.6tb",         "du": "11gb",         "hc": "4gb",         "hm": "29gb",         "hp": "13",         "ip": "172.27.201.68",         "rc": "31.4gb",         "rm": "58gb",         "rp": "54",         "cpu": "8",         "dup": "0.64",         "name": "instance-0000000064",         "role": "hrst",         "master": "-"       },       {         "dt": "1.6tb",         "du": "11gb",         "hc": "14.7gb",         "hm": "29gb",         "hp": "50",         "ip": "172.27.206.153",         "rc": "31.4gb",         "rm": "58gb",         "rp": "54",         "cpu": "8",         "dup": "0.63",         "name": "instance-0000000067",         "role": "hrst",         "master": "-"       },       {         "dt": "1.6tb",         "du": "10.9gb",         "hc": "16.5gb",         "hm": "29gb",         "hp": "57",         "ip": "172.27.202.244",         "rc": "31.5gb",         "rm": "58gb",         "rp": "54",         "cpu": "6",         "dup": "0.63",         "name": "instance-0000000068",         "role": "hrst",         "master": "-"       },       {         "dt": "1.6tb",         "du": "615.8mb",         "hc": "7.3gb",         "hm": "29gb",         "hp": "25",         "ip": "172.27.206.144",         "rc": "31.4gb",         "rm": "58gb",         "rp": "54",         "cpu": "12",         "dup": "0.03",         "name": "instance-0000000083",         "role": "hrst",         "master": "-"       },       {         "dt": "1.7tb",         "du": "264.8gb",         "hc": "18.8gb",         "hm": "30gb",         "hp": "62",         "ip": "172.27.207.187",         "rc": "53.7gb",         "rm": "60gb",         "rp": "90",         "cpu": "9",         "dup": "15.03",         "name": "instance-0000000104",         "role": "hrst",         "master": "-"       },       {         "dt": "1.7tb",         "du": "246.3gb",         "hc": "19.9gb",         "hm": "30gb",         "hp": "66",         "ip": "172.27.204.91",         "rc": "48.8gb",         "rm": "60gb",         "rp": "81",         "cpu": "7",         "dup": "13.98",         "name": "instance-0000000103",         "role": "hrst",         "master": "-"       },       {         "dt": "1.7tb",         "du": "287.4gb",         "hc": "7.7gb",         "hm": "30gb",         "hp": "25",         "ip": "172.27.210.42",         "rc": "48gb",         "rm": "60gb",         "rp": "80",         "cpu": "6",         "dup": "16.31",         "name": "instance-0000000105",         "role": "hrst",         "master": "-"       },       {         "dt": "225gb",         "du": "237.2mb",         "hc": "2.8gb",         "hm": "7.5gb",         "hp": "38",         "ip": "172.27.201.61",         "rc": "8.6gb",         "rm": "15gb",         "rp": "58",         "cpu": "8",         "dup": "0.10",         "name": "instance-0000000112",         "role": "ir",         "master": "-"       },       {         "dt": "225gb",         "du": "211.8mb",         "hc": "3.2gb",         "hm": "7.5gb",         "hp": "43",         "ip": "172.27.208.165",         "rc": "8.7gb",         "rm": "15gb",         "rp": "59",         "cpu": "8",         "dup": "0.09",         "name": "instance-0000000116",         "role": "ir",         "master": "-"       },       {         "dt": "225gb",         "du": "223.2mb",         "hc": "4.5gb",         "hm": "7.5gb",         "hp": "60",         "ip": "172.27.207.215",         "rc": "8.7gb",         "rm": "15gb",         "rp": "58",         "cpu": "8",         "dup": "0.10",         "name": "instance-0000000109",         "role": "ir",         "master": "-"       },       {         "dt": "150gb",         "du": "4.5gb",         "hc": "2.8gb",         "hm": "7.5gb",         "hp": "38",         "ip": "172.27.202.192",         "rc": "9gb",         "rm": "15gb",         "rp": "60",         "cpu": "8",         "dup": "3.04",         "name": "instance-0000000016",         "role": "ir",         "master": "-"       },       {         "dt": "150gb",         "du": "4.4gb",         "hc": "3.2gb",         "hm": "7.5gb",         "hp": "43",         "ip": "172.27.210.44",         "rc": "9.1gb",         "rm": "15gb",         "rp": "61",         "cpu": "8",         "dup": "2.96",         "name": "instance-0000000015",         "role": "ir",         "master": "-"       },       {         "dt": "150gb",         "du": "4.3gb",         "hc": "4.2gb",         "hm": "7.5gb",         "hp": "56",         "ip": "172.27.206.115",         "rc": "9.1gb",         "rm": "15gb",         "rp": "61",         "cpu": "7",         "dup": "2.92",         "name": "instance-0000000033",         "role": "ir",         "master": "-"       },       {         "dt": "150gb",         "du": "4.5gb",         "hc": "4.9gb",         "hm": "7.5gb",         "hp": "65",         "ip": "172.27.206.186",         "rc": "8.8gb",         "rm": "15gb",         "rp": "59",         "cpu": "14",         "dup": "3.02",         "name": "instance-0000000017",         "role": "ir",         "master": "-"       },       {         "dt": "225gb",         "du": "203mb",         "hc": "1.3gb",         "hm": "7.5gb",         "hp": "18",         "ip": "172.27.207.185",         "rc": "8.8gb",         "rm": "15gb",         "rp": "59",         "cpu": "9",         "dup": "0.09",         "name": "instance-0000000110",         "role": "ir",         "master": "-"       },       {         "dt": "150gb",         "du": "4.4gb",         "hc": "1.9gb",         "hm": "7.5gb",         "hp": "26",         "ip": "172.27.211.83",         "rc": "9.1gb",         "rm": "15gb",         "rp": "61",         "cpu": "11",         "dup": "2.96",         "name": "instance-0000000031",         "role": "ir",         "master": "-"       },       {         "dt": "150gb",         "du": "4.4gb",         "hc": "847.2mb",         "hm": "7.5gb",         "hp": "11",         "ip": "172.27.202.96",         "rc": "9.2gb",         "rm": "15gb",         "rp": "61",         "cpu": "9",         "dup": "2.94",         "name": "instance-0000000032",         "role": "ir",         "master": "-"       },       {         "dt": "225gb",         "du": "236.6mb",         "hc": "3gb",         "hm": "7.5gb",         "hp": "40",         "ip": "172.27.211.95",         "rc": "8.7gb",         "rm": "15gb",         "rp": "59",         "cpu": "8",         "dup": "0.10",         "name": "instance-0000000117",         "role": "ir",         "master": "-"       },       {         "dt": "150gb",         "du": "4gb",         "hc": "4.4gb",         "hm": "7.5gb",         "hp": "59",         "ip": "172.27.205.118",         "rc": "9gb",         "rm": "15gb",         "rp": "60",         "cpu": "8",         "dup": "2.69",         "name": "instance-0000000065",         "role": "ir",         "master": "-"       },       {         "dt": "225gb",         "du": "214.9mb",         "hc": "3.1gb",         "hm": "7.5gb",         "hp": "41",         "ip": "172.27.209.242",         "rc": "8.6gb",         "rm": "15gb",         "rp": "58",         "cpu": "8",         "dup": "0.09",         "name": "instance-0000000115",         "role": "ir",         "master": "-"       },       {         "dt": "150gb",         "du": "4.4gb",         "hc": "1.1gb",         "hm": "7.5gb",         "hp": "14",         "ip": "172.27.200.33",         "rc": "9gb",         "rm": "15gb",         "rp": "60",         "cpu": "8",         "dup": "3.00",         "name": "instance-0000000038",         "role": "ir",         "master": "-"       },       {         "dt": "225gb",         "du": "201.1mb",         "hc": "4.6gb",         "hm": "7.5gb",         "hp": "62",         "ip": "172.27.203.13",         "rc": "8.8gb",         "rm": "15gb",         "rp": "59",         "cpu": "14",         "dup": "0.09",         "name": "instance-0000000113",         "role": "ir",         "master": "-"       },       {         "dt": "225gb",         "du": "193mb",         "hc": "1.4gb",         "hm": "7.5gb",         "hp": "19",         "ip": "172.27.203.13",         "rc": "8.7gb",         "rm": "15gb",         "rp": "59",         "cpu": "19",         "dup": "0.08",         "name": "instance-0000000114",         "role": "ir",         "master": "-"       },       {         "dt": "225gb",         "du": "238.3mb",         "hc": "4gb",         "hm": "7.5gb",         "hp": "53",         "ip": "172.27.207.215",         "rc": "8.7gb",         "rm": "15gb",         "rp": "59",         "cpu": "9",         "dup": "0.10",         "name": "instance-0000000111",         "role": "ir",         "master": "-"       },       {         "dt": "150gb",         "du": "1018mb",         "hc": "1.9gb",         "hm": "7.5gb",         "hp": "25",         "ip": "172.27.210.109",         "rc": "9gb",         "rm": "15gb",         "rp": "60",         "cpu": "7",         "dup": "0.66",         "name": "instance-0000000086",         "role": "ir",         "master": "-"       },       {         "dt": "150gb",         "du": "224.8mb",         "hc": "3.5gb",         "hm": "6gb",         "hp": "59",         "ip": "172.27.207.58",         "rc": "7gb",         "rm": "15gb",         "rp": "47",         "cpu": "5",         "dup": "0.15",         "name": "instance-0000000087",         "role": "lr",         "master": "-"       },       {         "dt": "192gb",         "du": "5mb",         "hc": "3.5gb",         "hm": "6.3gb",         "hp": "56",         "ip": "172.27.202.111",         "rc": "7.3gb",         "rm": "16gb",         "rp": "46",         "cpu": "2",         "dup": "0.00",         "name": "instance-0000000118",         "role": "lr",         "master": "-"       },       {         "dt": "450gb",         "du": "2.5gb",         "hc": "2.5gb",         "hm": "7.5gb",         "hp": "33",         "ip": "172.27.204.62",         "rc": "8.5gb",         "rm": "15gb",         "rp": "57",         "cpu": "2",         "dup": "0.56",         "name": "instance-0000000119",         "role": "mr",         "master": "-"       },       {         "dt": "450gb",         "du": "2.5gb",         "hc": "3.6gb",         "hm": "7.5gb",         "hp": "48",         "ip": "172.27.202.61",         "rc": "8.5gb",         "rm": "15gb",         "rp": "57",         "cpu": "2",         "dup": "0.57",         "name": "instance-0000000121",         "role": "mr",         "master": "-"       },       {         "dt": "960gb",         "du": "5.4gb",         "hc": "8gb",         "hm": "16gb",         "hp": "50",         "ip": "172.27.200.204",         "rc": "17.4gb",         "rm": "32gb",         "rp": "55",         "cpu": "1",         "dup": "0.57",         "name": "instance-0000000100",         "role": "mr",         "master": "-"       },       {         "dt": "204gb",         "du": "2.8gb",         "hc": "7.9gb",         "hm": "8.5gb",         "hp": "93",         "ip": "172.27.201.141",         "rc": "9.7gb",         "rm": "17gb",         "rp": "57",         "cpu": "33",         "dup": "1.42",         "name": "instance-0000000095",         "role": "mr",         "master": "*"       },       {         "dt": "960gb",         "du": "5.4gb",         "hc": "9.6gb",         "hm": "16gb",         "hp": "60",         "ip": "172.27.204.209",         "rc": "17.3gb",         "rm": "32gb",         "rp": "54",         "cpu": "1",         "dup": "0.57",         "name": "instance-0000000102",         "role": "mr",         "master": "-"       },       {         "dt": "10.7tb",         "du": "1.2tb",         "hc": "16.2gb",         "hm": "30gb",         "hp": "54",         "ip": "172.27.208.251",         "rc": "53.1gb",         "rm": "60gb",         "rp": "89",         "cpu": "7",         "dup": "11.65",         "name": "instance-0000000060",         "role": "rw",         "master": "-"       },       {         "dt": "10.7tb",         "du": "1.2tb",         "hc": "10.5gb",         "hm": "30gb",         "hp": "35",         "ip": "172.27.201.96",         "rc": "53.1gb",         "rm": "60gb",         "rp": "89",         "cpu": "17",         "dup": "11.65",         "name": "instance-0000000059",         "role": "rw",         "master": "-"       }     ]   },   "status": "Success",   "message": "",   "operation": null }

Thanks for your help!
