Troubleshooting Tip: Certificate file is not a CA file

  • October 19, 2020
  • 0 replies
  • 10039 views

Description


This article describes how to resolve the 'Certificate file is not a CA file' error that occurs when uploading a CA certificate in the firewall.



Scope



Any version of FortiGate.

Solution


When the CA certificate is uploaded in the firewall as a CA certificate, the firewall may provide an error stating 'Certificate file is not a CA file' even though the certificate shows as a CA certificate.
To upload the certificate in the firewall as a CA certificate, the Basic Constraints parameter in the certificate must state that CA=true.
If this field is not present, the firewall will not accept the certificate as a CA certificate.


See the screenshot below:






Note: To decode the CA certificate on the local computer, run the following OpenSSL command:



openssl x509 -in ca_certificate_name.crt -text -noout
