Technical Tip: Upgrade incomplete error message after firmware upgrade in Fabric management

  • April 6, 2025
  • 0 replies
  • 1930 views
Description

This article describes post upgrading FortiGate could see message 'Upgrade Incomplete' in the Fabric Management page.




Scope FortiGate.
Solution
  • Verify whether the FortiGate status and the device show a completed upgrade to the desired firmware version.



get system status



Example output:



Version: FortiGate-VM64-KVM v7.2.8,build1639,240313 (GA.M)
Security Level: 1
Firmware Signature: certified



  • If the device is in HA, verify HA status between both devices and any sync errors.



get system ha status



  • Verify if there are any configuration error messages



diagnose debug config-error-log read



If all of the settings are working as expected, cancel the error message:

System -> Fabric Management -> Select the device and choose 'cancel'. The error message will be removed.



If it persists: clear the browser cache and cookies, try another browser, or use incognito mode.
