Technical Tip: Dual Power supplies for FortiGate 300E and FortiGate 500E series

  • February 9, 2018
  • 0 replies
  • 6343 views

Description


This article describes how the FortiGate 300E and FortiGate 500E series are supplied with a single power supply and have a slot available for an additional power supply.

Scope

FortiGate.

Solution
Additional power supplies can be ordered (SP-FG300E-PS) and inserted the item into the slot.

The power supplies are hot-swappable.

Murata provides these power supplies and corresponds exactly to the model Murata D1U54P-W-450-12-HB4C.
