Technical Tip: Configure hairpin NAT with Virtual Server

  • May 27, 2026
  • 0 replies
  • 107 views



Description

This article describes how to set up a hairpin NAT to allow clients located behind the same interface as the real servers to access services using the virtual IP address.



Scope

FortiOS v7.4+.

Solution

This article assumes that the Virtual Server is already configured and is accessible from external interfaces such as the WAN. In this example, the Virtual server is configured as follows:

config firewall vip
    edit "VirtualServer"
        set type server-load-balance
        set server-type tcp
        set extip 100.64.100.100
        set extintf "wan1"
        set monitor "Ping-Monitor"
        set ldb-method round-robin
        set extport 8080
            config realservers
                edit 1
                    set ip 192.168.10.2
                    set port 80
                next
                edit 2
                    set ip 192.168.10.3
                    set port 80
                next
            end
        next
    end


For information on how to configure a virtual server, refer to the following article: Technical Tip: Configure a virtual server.


If the Client machine with IP 192.168.10.100 needs to connect to the virtual server using the external IP address 100.64.100.100,

The following changes need to be applied.


Step 1: Change the external interface in the VIP to 'any'.

config firewall vip
    edit "VirtualServer"
        set extintf "any"
    next
end


This is required to allow the object to be referenced in the next step.


Step 2: Configure a Firewall policy in proxy mode and set the destination to be the Virtual server object.



config firewall policy
    edit 29
        set name "Test Virtual Server"
        set uuid 3260d4f2-4e46-51f1-849a-ab15ca94a9f0
        set srcintf "port1"
        set dstintf "port1"
        set action accept
        set srcaddr "all"
        set dstaddr ""Test Virtual Server" <----- Reference the Virtual server object (VIP).
        set schedule "always"
        set service "ALL"
        set inspection-mode proxy  <----- This is mandatory.
        set logtraffic all
        set nat enable
    next
end
