Troubleshooting Tip: How to fix the issue of FortiClient EMS upgrade failure with error '0x86430003'

  • February 4, 2026
  • 0 replies
  • 548 views
Description This article describes how to fix the issue of error '0x86430003' during the FortiClient EMS upgrade.
Scope FortiClient EMS v7.2.7+.
Solution

When upgrading FortiClient EMS to 7.2.7+ failed, in the FortiClient EMS log, the following error shows up.



[1B5C:4678][2025-09-19T05:47:13]e000: Error 0x86430003: Process returned error: 0x86430003
[1B5C:4678][2025-09-19T05:47:13]e000: Error 0x86430003: Failed to execute EXE package.
[0D64:4AD0][2025-09-19T05:47:13]e000: Error 0x86430003: Failed to configure per-machine EXE package.
[0D64:4AD0][2025-09-19T05:47:13]i319: Applied execute package: sql_server_2022_cu, result: 0x86430003, restart: None



This is caused by the FortiClient EMS SQL Server Cumulative update installation failing. To fix this issue, download and install CU updates manually from the link below:
SQL Server® 2022 for Microsoft® Windows Latest Cumulative Update









After the above, reboot the FortiClient EMS server, followed by 'right-clicking' the upgrade package and running it as admin to upgrade FortiClient EMS again.
