Troubleshooting Tip: FortiClient free version can connect to SAML IPsec VPN, but FortiClient full client version is unable to connect to SAML IPsec VPN
| Description | This article describes how to troubleshoot a scenario whereby when using the FortiClient free version, the user can connect to SAML IPsec VPN, but when using the FortiClient full version, the user is unable to connect to SAML IPsec VPN. |
| Scope | FortiClient v7.2.4 and above. |
| Solution | IPsec VPN with SAML is a new supported feature starting from FortiClient v7.2.4, see IPsec VPN SAML-based authentication. Test case 1: When using the FortiClient free version, the user can connect to SAML IPsec VPN.
When reproducing the issue in Test case 2, run IKE debug on FortiGate:
diagnose debug disable diagnose debug reset diagnose debug console timestamp en diagnose vpn ike log filter rem-addr4 x.x.x.x <-- Replace x.x.x.x with the endpoint public IP. diagnose debug application ike -1 diagnose debug application fnbamd -1 diagnose debug application samld -1 diagnose debug enable The below output can be seen: 2024-11-25 00:07:49.678804 ike 0:VPN-SAML1: connection expiring due to phase1 down <--------- 2024-11-25 00:07:49.678822 ike 0:VPN-SAML1: deleting 2024-11-25 00:07:49.678843 ike 0:VPN-SAML1: deleted 2024-11-25 00:07:53.222643 ike 0: comes 71.163.111.183:4500->173.79.222.162:4500,ifind ex=7,vrf=0.... 2024-11-25 00:07:53.222700 ike 0: IKEv2 exchange=AUTH id=f08b5ff17757de23/feb6fae6e6da 1398:00000001 len=672 To disable debugs on FortiGate: diagnose debug disable diagnose debug reset In the FortiClient logs, the below output can be seen: [2024-11-25 00:47:05.6197183 UTC-04:00] [1480:7836] [FortiVPN 2223 error] !!! fortivpn::StateMachine::HandleTunnelDisconnected session 1 (companyA\imageadmin) "SAML-VPN" disconnected unexpectedly! [2024-11-25 00:52:51.9251778 UTC-04:00] [1480:7836] [FortiVPN 2223 error] !!! fortivpn::StateMachine::HandleTunnelDisconnected session 1 (companyA\imageadmin) "SAML-VPN" disconnected unexpectedly! [2024-11-25 00:59:27.0425154 UTC-04:00] [1480:7836] [FortiVPN 1874 error] fortivpn::StateMachine::HandleTunnelConnectFailed session 1's (companyA\imageadmin) vpn connection failed (reason: "Failed Unknown") [2024-11-25 00:59:27.0434631 UTC-04:00] [1480:7836] [FortiVPN 2223 error] !!! fortivpn::StateMachine::HandleTunnelDisconnected session 1 (companyA\imageadmin) "SAML-VPN" disconnected unexpectedly! This can be due to EAP is not being enabled in the FortiClient EMS endpoint profile. To fix this, go to FortiClient EMS -> Endpoint Profiles -> Remote Access -> (select) -> Edit -> (select the tunnel) -> Edit -> Advanced Settings -> Turn on 'Enable XAuth' -> Save the tunnel -> Save the profile.
